UNIQUE BENEFITS

• Dual Radio 802.11ac access point with Multi-User MIMO

  - Supports up to 1,733 Mbps in the 5 GHz band (with

  4SS/VHT80 or 2SS/VHT160 clients) and up to 800 Mbps

  in the 2.4 GHz band (with 4SS/VHT40 clients)
• Antenna polarization diversity for optimized RF performance

  - Each 5 GHz radio chain has a switch and two antennas

  - Software controlled; Horizontally and vertically polarized

• HPE Smart Rate uplink port that scales up to 5Gbps

  - Supports up to 5Gbps with NBase-T Ethernet compatibility

  - Backwards compatible with 100/1000Base-T
  - Adds support for hitless PoE failover between the HPE

  Smart Rate port and the secondary 1000Base-T port

  when both ports are powered

• Built-in Bluetooth Low-Energy (BLE) radio

- Enables location based services with BLE-enabled mobile devices receiving signals from multiple Aruba Beacons at the same time

• Advanced Cellular Coexistence (ACC)
- Minimizes interference from 3G/4G cellular networks,

distributed antenna systems and commercial small cell/femtocell equipment

• Quality of service for app visibility and control - Supports priority handling and policy enforcement

for uni ed communication apps, including Skype for Business with encrypted videoconferencing, voice, chat and desktop sharing

- Aruba AppRF technology leverages deep packet inspection to classify and block, prioritize or limit bandwidth for over 1,500 enterprise apps or groups of apps

• RF Management
- Adaptive Radio Management (ARM) technology

automatically assigns channel and power settings, provides airtime fairness and ensures that APs stay clear of all sources of RF interference to deliver reliable, high-performance WLANs

- The Aruba 330 Series Access Points can be con gured to provide part-time or dedicated air monitoring for spectrum analysis and wireless intrusion protection, VPN tunnels to extend remote locations to corporate resources, and wireless mesh connections where Ethernet drops are not available

• Spectrum analysis
- Capable of part-time or dedicated air monitoring, the

spectrum analyzer remotely scans the 2.4 GHz and
5 GHz radio bands to identify sources of RF interference from HT20 through VHT160 operation

• Security
- Integrated wireless intrusion protection o ers threat

protection and mitigation, and eliminates the need for

separate RF sensors and security appliances - IP reputation and security services identify, classify,

and block malicious les, URLs and IPs, providing

comprehensive protection against advanced online threats - Integrated Trusted Platform Module (TPM) for secure

storage of credentials and keys - SecureJack-capable for secure tunneling of wired

Ethernet tra c
• Intelligent Power Monitoring (IPM)

- Enables the AP to continuously monitor and report its actual power consumption and optionally make autonomous decisions to disable certain capabilities based on the amount of power available to the unit

- Software con gurable to disable capabilities in certain orders. For the 330 Series Access Points, by default, the USB interface will be the rst feature to turn o if the AP power consumption exceeds the available power budget
